Doors are manufactured after the order has been placed through the website.
Production time for our doors:
door named PIVOT (aluminum) - production takes 7 weeks
Size pivot door with frame:
Width from: 55.1" to 72"
Height from: 78.7" to 116"
Pivot doors represent the best doors the market can offer and deliver maximum comfort and security for the user, while allowing substantial architectural freedom with numerous design variants and scoring high on energy-efficiency.
Pivot door are a versatile solution to make an architectural statement in any residential of public building.
Technical specifications
Air tightness max. test pressure 4 (600 Pa)
Water tightness 4A (150 Pa)
Wind load resistance C3 (1200 Pa)
Burglar resistance RC2/WK2
Thermal insulation R-Value 5.5
- frame depth door: 78 mm / 3.1",
- Depth Vent: 78 mm / 3.1"
- Air tightness: Class 4 (600Pa)
- Wind load resistance: Class C3 (1200Pa)
- Water tightness: Class 4A (150Pa)
- Opening & closing resistance: Class 5
- standard glazing package 4th/16Ar/4/16Ar/4th [Ug=0,6]*
- Burglar resistance: RC2
- Thermal insulation: Ud = 1.1 W/K*m2 / R-Value 5.5
Pivot door cross-section in full glass version
Pivot door cross-section with an aluminum overlay panel
>
Glazing
The glass in our doors are triple-pane windows. All panes are connected with spacer frames. Two of them are covered with Low-E coatings that provide natural light while helping to limit heat gain and thermal energy loss. It is also possible to choose P4 anti-burglary glass or safety glass VSG 33.1standard glazing package 4th/16Ar/4/16Ar/4th
safety glass 33.1//4//4
P4 anti-burglary
Types of glazing
There is a wide range of glass options. In our offer one will find energy-saving, sound-absorbing, safety, anti-burglary and sunscreen windows. The most popular ones are milk glass, decorative or mirror glass as well as bronze reflex glass.Colours
Colours can emphasise the shape of aluminium joinery and provide it with individual character and genuine appearance. All aluminium systems offered are available in two colour palettes – RAL and DECORAL.Fiery red or maybe a delicate blue? The RAL K5 Classic colour palette will allow you to choose the colour of the door perfectly suited to your requirements!
RAL 1003
RAL 2004
RAL 3020
RAL 5002
RAL 6005
RAL 6021
RAL 7016
RAL 7039
RAL 7040
RAL 9016
RAL 9005
RAL 9007
DECORAL woodgrain finish palette
Aluminium doors can also have more traditional, woodlike finishes such as: beech, sweet cherry, golden oak, winchester, mahogany, walnut, dark oak, pine, cherry, wenge.
Golden Oak
Mahogany
Winchester
Dark Oak
The door set includes:
- Aluminum pivot door and the door frame;
- long vertical handle / normal handle outside;
- the door handle inside;
- FUHR 833 3-point lock
- low threshold door
- Standard lock insert with 5 keys.
